Quality Is Our Attitude
| Bore(mm) | 32 | 40 | 50 | 63 | 80 | 100 |
| Acting type | Double acting | |||||
| Working medium | ClAan air(40μm filteration) | |||||
| Working pressure | 0.1~1.0Mpa (14.5~145psi/1~10bar) | |||||
| Guaranteed pressure | 1.5Mpa (215psi/15bar) | |||||
| Working temperature (ºC) | -20-80(No freezing) | |||||
| Speed range (mm/s) | 30-800 | |||||
| Cushion type (mm) | Air cushion | |||||
| Cushion stroke | 27 | 30 | 36 | |||
| Mounting type | LB FA FB CA CB CR | |||||
| Port size G/PT/NPT | G1/8" | G1/4" | G3/8" | G1/2" | ||
