HLP830 Pressure Controls with SPDT Max.30Bar

Model		Pressure rang(MPa)		Differential pressure range(MPa)		Factory setting(MPa)		Max pressure(MPa)
Model		Max.	Min.	Max.	Min.	Off	On	Max pressure(MPa)
HLP110		0.1	1	0.1	0.3	0.6±0.01	0.5±0.01	1.65
HLP506		-0.07	0.6	0.06	0.4	0.3±0.01	0.2±0.01	1.65
HLP506M		-0.07	0.6	Duplicate voltage disparity≤0.4		0.3±0.01	Manual reset	1.65
HLP530		0.5	3	Fixed 0.3 to 0.5		2±0.01	1.5±0.02	3.5
HLP530D		0.5	3	0.5	1	2±0.01	1.5±0.02	3.5
HLP530M		0.5	3	Duplicate voltage disparity≤0.4		2±0.02	Manual reset	3.5
HLP830	Low pressure end	-0.07	0.6	0.06	0.4	0.3±0.01	0.2±0.01	1.65
HLP830	High pressure end	0.5	3	Fixed 0.3 to 0.5		2±0.02	1.5±0.02	3.5
HLP830HLM	Low pressure end	-0.07	0.6	Duplicate voltage disparity≤0.2		0.3±0.01	Manual reset	1.65
HLP830HLM	High pressure end	0.5	3	Duplicate voltage disparity≤0.4		2±0.02	Manual reset	3.5
HLP830HM	Low pressure end	-0.07	0.6	0.06	0.4	0.3±0.01	0.2±0.01	1.65
HLP830HM	High pressure end	0.5	3	Duplicate voltage disparity≤0.4		2±0.02	Manual reset	3.5
HLP830M	Low pressure end	-0.07	0.6	0.06	0.4	0.3±0.01	0.2±0.01	1.65
HLP830M	High pressure end	0.5	1	Duplicate voltage disparity≤0.4		2±0.02	Manual reset	3.5

Make an Enquiry

Contact Our Regis on ,
or perhaps you'd like to mail us for details.

REGIS HINTS

1/4, UNF7/16 or special connection can be available

Widely used in HVAC, petrochemical, water treatment, manufacturing and other fields.
