| Bore(mm) | 12 | 16 | 20 | 25 | 32 | 40 | 50 | 63 | 80 | 100 |
| Acting type | Double Acting | |||||||||
| Single acting spring extend,Single acting spring return | ||||||||||
| Working medium | Clean air(40um Filteration) | |||||||||
| Pressure range | Double Acting:0.1-0.9Mpa | |||||||||
| Single acting:0.2-0.9Mpa | ||||||||||
| Guaranteed Pressure | 1.5Mpa(213psi) | |||||||||
| Working temperature | -5-70ºC | |||||||||
| Speed range | Double acting:30-500mm/s | 30-350mm/s | 30-250mm/s | |||||||
| Single acting:100-500mm/s | ||||||||||
| Cushion type | Fized cushion | |||||||||
| Port size | M5*0.8 | G1/8" | G1/4'' | G3/8'' | ||||||
