| Bore(mm) | 12 | 16 | 20 | 25 | 32 | 40 | 50 | 63 | 80 | 100 | |
| Acting type | Double acting | ||||||||||
| Single Acting Spring Extend,Single Acting Spring Return | - | ||||||||||
| Working medium | Clean air(40μm Filteration) | ||||||||||
| Pressure range | Double acting | 0.1~0.9Mpa | |||||||||
| Single acting | 0.2~0.9Mpa | - | |||||||||
| Guaranteed pressure | 1.5Mpa | ||||||||||
| Working temperature | -5~70ºC | ||||||||||
| Speed range | Double acting | 30~500mm/s | 30~350mm/s | 30~250mm/s | |||||||
| Single acting | 100-500mm/s | - | |||||||||
| Cushion type | Fixed Cushion | ||||||||||
| Port size | M5X0.8 | G1/8 | G1/4 | G3/8 | |||||||
REGIS HINTS
• Riveted structure is adopted to connect the cylinder body and back cover, as well as piston and piston rod to make it compact and reliable.
• The seal of piston adopts heterogeneous two-way seal structure to achieve a compact size and grease storage.
