| Model | Specification | Bracket | ||||
| Minimal Flow of Oil Drop | Flow Rate* | SCFM* Cubic Feet /min | Port Size | Bowl Capacity | ||
| (L/min) | (L/min) | (cm³) | ||||
| AL1000-M5 | 4 | 95 | 3.4 | M5 | 7 | - |
| AL2000-01 | 15 | 800 | 28.3 | 1/8" | 25 | B240 |
| AL2000-02 | 1/4" | |||||
| AL3000-02 | 30 | 1700 | 60 | 1/4" | 50 | B340 |
| AL3000-03 | 40 | 3/8" | ||||
| AL4000-03 | 40 | 5000 | 177 | 3/8" | 130 | B440 |
| AL4000-04 | 50 | 1/2" | ||||
| AL4000-06 | 50 | 6300 | 222 | 3/4" | 130 | B540 |
| AL5000-06 | 190 | 7000 | 247 | 3/4" | 130 | B640 |
| AL5000-10 | 1 | |||||
